- Input frequencies: 10.7~11.7 GHz, High Band: 11.7~12.75 GHz
- Number of outputs: 4 (1VL, 1HL, 1VH, 1HH)
- Output frequencies: 950~1950 MHz, 1100~2150 MHz
- Local oscillators: 9.75 GHz, 10.60 GHz
- Output impedance 75
- Conversion gain: 55-65 dB
- Noise figure: 0.1 dB max.
- Voltage supply: 11.5-19.0 VDC
- Current consumption: 200±10 mA
